The down-the-hole dth hammer is a device that uses compressed air as a power source and uses the reciprocating motion of the piston in the hammer to impact the drill bit to break the rock. The down-the-hole dth hammer is a working device of the down-the-hole drill. According to the working pressure of the dth hammer, it can be divided into low-pressure dth hammer (working pressure is 0.5~0.7Mpa), medium-pressure dth hammer (0.7~1.2Mpa) and high-pressure dth hammer(above 1.2Mpa); according to the gas distribution method and structural characteristics of the dth hammer, it can be divided into valved and valveless types; according to the formation of the central through hole of the down-the-hole dth hammer, it can be divided into ordinary down-the-hole dth hammer and reverse circulation down-the-hole dth hammer.

Application :

It is widely used in large-scale open-pit and underground ore mining, anchoring engineering, quarrying and rock drilling, water well geothermal mining, construction engineering rock drilling and large-scale engineering construction, etc.

Features

1 The operating air pressure are between 0.5Mpa and 0.7Mpa
2 Valveless hammers.
3 Simple structure, easy to assemble and to disassemble, long life span.
4 Higher impact frequency and faster drilling speed.
5 Lower air consumption and lower oil consumption. A hole can be drilled on the check valve to provide more efficient cuttings discharge.
6 Especially suitable for quarrying.
